XP4025-BK1023 ASA PC Material Weather Resistant Energy Alloy Plastic
Product Details:
| Place of Origin: | American |
| Brand Name: | American basic innovation |
| Certification: | MSDS |
| Model Number: | ASA/PC XP4025-BK1023 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25KG |
|---|---|
| Price: | USD2.5-3KG |
| Packaging Details: | 25 kg/pack |
| Delivery Time: | 7-15days |
| Payment Terms: | T/T |
| Supply Ability: | 500T |
|
Detail Information |
|||
| Melt Index 260℃5kg: | 18cm3/10min | Port: | ShenZhen/GuangZhou,China |
|---|---|---|---|
| Application: | Injection Molding | Material: | Alloy |
| Electrical Conductivity: | Non-conductive | Surface Finish: | Smooth |
| Chemical Resistance: | Excellent | Tensile Strength: | 50 MPa |
| Plastic Type: | Thermoplastic | ||
| Highlight: | XP4025-BK1023 ASA PC Material,Weather Resistant ASA PC Material,Energy Alloy Plastic PC ASA Resin |
||
Product Description
Products Description
|
|
ASA/PC American basic innovation XP4025-BK1023 weather resistant energy alloy plastic |
ASA/PC American basic innovation XP4025-BK1023 weather resistant energy alloy plastic
product feature
| SABIC Innovative Plastics GELOY XP4025 ASA+PC(Asia Pacific) | |||
| Polycarbonate/ASA Alloy,Unreinforced | |||
| SABIC Innovative Plastics(GE Plastics) product description |
|||
| ASA+PC blend.Weatherable,injection grade.Available in a wide range of colors and is recommended for unpainted exterior applications. | |||
| Physical property | Rated value(metric) | Rated value(English) | Test method |
| Proportion Water absorption |
1.14 g/cc | 1.14 g/cc | ASTM D792 |
| 0.24% | 0.24% | ||
| @Time 86400 sec | @Time 24.0 hour | ASTM D570 | |
| Linear molding shrinkage, | 0.0050-0.0070 cm/cm | 0.0050-0.0070 in/in | |
| Flow | @Thickness 3.20 mm | @Thickness 0.126 in | SABIC Method |
| Linear molding shrinkage, | 0.0050-0.0070 cm/cm | 0.0050-0.0070 in/in | |
transverse Melt flow rate @ |
@Thickness 3.20 mm | @Thickness 0.126 in | SABIC Method |
| 18 g/10 min | 18 g/10 min | ||
| Load 5.00 kg,Temperature 260℃ | @Load 11.0 Ib,Temperature 500F | ASTM D1238 | |
| Mechanical behavior | Rated value(metric) | Rated value (English) | Test method |
| Rockwell hardness(R class) | 114 | 114 | ASTM D785 |
| Tensile strength(yield) | 59.0 MPa | 8560 psi | Type I,50 mm/min;ASTM D638 |
| Elongation(break) | 25% | 25% | Type I,50 mm/min;ASTM D638 |
| bending strength | 88.0 MPa | 12800 psi | 1.3 mm/min,50 mm span;ASTM |
| flexural modulus | 2.58 GPa | 374 ksi | 1.3 mm/min,50 mm span;ASTM |
| Impact strength of hanging beam | |||
gap |
1.70J/cm | 3.18 ft-lb/in | ASTM D256 |
| 0.640 J/cm | 1.20 ft-Ib/in | ||
| @Temperature -30.0℃ | @Temperature -22.0°F | ASTM D256 | |
Dart Drop,Total Energy |
33.0J | 24.3 ft-Ib | |
| @Temperature -30.0℃ | @Temperature -22.0F | ASTM D3763 | |
| 37.0J | 27.3 ft-Ib | ||
| @Temperature 23.0℃ | @Temperature 73.4°F | ASTM D3763 | |
| Hot property | Rated value(metric) | Rated value (English) | Test method |
| Linear thermal expansion | 72.0μm/m-℃ | 40.0 μin/in-F | |
| coefficient-flow | @Temperature -20.0-150℃ | @Temperature -4.00-302F | ASTME831 |
| Linear thermal expansion coeffi- | 72.0 μm/m-℃ | 40.0 μin/in-F | |
| cient,lateral flow | @Temperature -20.0-150℃ | @Temperature -4.00-302F | ASTM E831 |
| Thermal conductivity | 0.250 W/m-K | 1.74 BTU-in/hr-ft²-F | ASTM C177 |
| Thermal deformation temperature | 102℃ | 216F | |
| under load(0.46 MPa) | @Thickness 3.20 mm | @Thickness 0.126 in | unannealed;ASTM D648 |
| Thermal deformation temperature | 90.0℃ | 194F | |
| under load (1.8 MPa) | @Thickness 6.40 mm | @Thickness 0.252 in | unannealed;ASTM D648 |
| UL RTI | 50.0℃ | 122F | UL 746B |
| UL RTI Mechanical shock | 50.0℃ | 122F | UL 746B |
| UL RTI,no mechanical impact | 50.0℃ | 122F | UL 746B |
| Flammability(UL94) | HB @Thickness 1.47 mm |
HB @Thickness 0.0579 in |
UL94 |
| Optical performance | Rated value(metric) | Rated value (English) | Test method |
| glossiness | 90% | 90% | untextured,60 degrees;ASTM D5 |
Application
 |
|
|
Optical lighting
It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft. |
Electronic appliances
It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on. |
Mechanical equipment
It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields |
Physical Property Parameter
