Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde

Product Details:

Place of Origin: Korean
Brand Name: Korean Engineering
Model Number: POM/PTFE FL2010
Document: Company color page PC..pdf

Payment & Shipping Terms:

Minimum Order Quantity: 25
Price: USD 3.7-4.2
Packaging Details: PE plastic Bag
Delivery Time: 7-15days
Payment Terms: T/T
Supply Ability: 500TONS
Get Best Price Contact Now

Detail Information

Product Name: POM/PTFE FL2010 Color: Natural
Material Shape: Pellets Grade: Injection Molding Grade
MOQ: 1 Ton Packing: 25KG PE Bag
Application: Electrical Application Type: 100% Virgin Material
Delivery Time: 7-15days Port: ShenZhen/GuangZhou,China

Product Description



Products Description















Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 0

Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde



product feature



POM 770/1 PTFE20

Product information



Other Certificates RoHS REACH

Part Marking Code POM



Process Injection molding

Polymer

Material Attribute

Copolymer
20%PTFE Filler Wear resistant grade
specification ·REACH·RoHS
Application

·Automotive applications ·Bearing·Functional components ·Gears ·Machinery parts

·Rollers·Sliding element



Certificate



EAC


Physical property Standard Value Unit
Density ISO 1183 1500 kg/m³
Shrinkage Flow 24hr ISO 294 1.5~1.7 %
Shrinkage xFlow 24hr ISO 294 1.7~1.9 %
Melt Index 190℃ 2.16kg ISO 1133 6 cm³/10min
Mechanical behavior Standard Value Unit
Tensile Modulus ISO 527 2400 MPa
Tensile Strength Yield ISO 527 48 MPa
Elongation Yield ISO 527 9.4 %
Elongation Break ISO 527 17 %
Flexural Strength ISO 178 70 MPa
Flexural Modulus ISO 178 2500 MPa
Charpy Notch Impact leA ISO 179 4 kJ/m²
Charpy Notch Impact -40℃ leA ISO 179 3 kJ/m²
Charpy Un-notch Impact ISO 179 50 kJ/m²
Charpy Un-notch Impact -40℃ ISO 179 60 kJ/m²
Thermal Standard Value Unit
HDT 1.8MPa ISO 75 95
Vicat Softening Temperature 50℃/hr 50N ISO 306 143
Melting Temperature DSC ISO 11357 172
Injection molding   Value Unit
Dry Temperature   100~110
Dry Temperature   100~110
Dry Time   2~3 hr
Dry Time   3~5 hr
Melt Temperature   180~220
Mould Temperature   60~120



Application





Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 1 Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 2



Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 3

Optical lighting



It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 4Electronic appliances



It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 5Mechanical equipment



It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields



Physical Property Parameter​

Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 6

Korean Engineering POM FL2010 Low wear 10%PTFE filled automotive parts injection grade polyformaldehyde 7
