Product Details:

Place of Origin: America
Brand Name: Basic Innovative Plastics
Certification: MSDS
Model Number: PA66 AFR200Y

Payment & Shipping Terms:

Minimum Order Quantity: 25KG
Price: USD2.5-3.3KG
Packaging Details: PE plastic/paper bag
Delivery Time: 7-15days
Payment Terms: T/T
Supply Ability: 500TONS
Get Best Price Contact Now

Detail Information

Material: PA66 AFR200Y Color: Natural Color
Material Shape: Pellets Grade: Injection Molding Grade
MOQ: 25KG Packing: 25 Kg/pack
Application: Cosmetic Application Delivery Time: 7-15days
Port: ShenZhen/GuangZhou,China
Highlight:

AFR200Y PA66 Material

,

Home Appliance Parts PA66 Material

,

Environmental Friendly Polyamide 66 Resin

Product Description



Products Description















AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 0















 PA66 Basic Innovative Plastics (USA) AFR200Y Heat Stabilized injection-grade UV resistant home appliance parts



PA66 AFR200Y as a high performance engineering plastic, its performance mainly includes the following aspects:
Flame retardant properties: PA66 AFR200Y is flame retardant, meaning it is capable of self-extinguishing upon contact with a flame, which makes it very popular in electronic and electrical applications where fire safety is strictly required.
Thermal stability: PA66 AFR200Y has good thermal stability and is able to maintain its physical and mechanical properties in high temperature environments, which makes it suitable for the manufacture of parts that need to withstand high temperatures.
Mechanical properties: PA66 AFR200Y has excellent mechanical properties, including high strength, high rigidity and good toughness. These characteristics allow it to be used in the manufacture of various load-bearing parts and structures.
Electrical insulation properties: PA66 AFR200Y has excellent electrical insulation properties, which is an important advantage for electrical and electronic applications, as it prevents current leakage and the occurrence of short circuits.
Chemical resistance: PA66 AFR200Y has good chemical resistance and can resist the erosion of many common chemicals and solvents, which makes it suitable for the manufacture of parts that require exposure to chemicals.
Processability: PA66 AFR200Y has good processability and can be easily processed into parts of various shapes and sizes by injection molding and other processes

product feature

PA66
AFR200Y
Product information
Part Marking Code >PA66-FR<
Color NC
Material Shape Pellets
Process Injection molding
FR V-0
Material Attribute Non Halogen Heat stabilized grade
Features ·Low (to None)Bromine Content ·Non-red phosphorus ·unfilled
Application ·E&E Applications · Industrial Applications · Injection molding applications
Additives Flame Retardant Agent Heat Stabilizer Mold Releases
Physical property Standard Value Unit
Density ISO 1183 1.17 g/cm³
Water Absorption 23℃50RH Equilibrium ISO 62 1.1 %
Water Absorption 23℃ Saturation ISO 62 7.5 %
Mechanical behavior Standard Value Unit
Tensile Modulus 23℃ ISO 527 3400 MPa
Tensile Strength Yield 23℃ ISO 527 80 MPa
Tensile Strength Break 23℃ ISO 527 78 MPa
Elongation Yield 23℃ ISO 527 4.8 %
Elongation Break 23℃ ISO 527 9 %
Flexural Strength 23℃ ISO 178 120 MPa
Flexural Modulus 23℃ ISO 178 3300 MPa
Izod Notch Impact 23℃ Type A ISO 180 4 kJ/m²
Izod Notch Impact -30℃ Type A ISO 180 3 kJ/m²
Izod Notch Impact -40℃ Type A ISO 180 3 kJ/m²
Charpy Notch Impact 23℃ 1eA ISO 179 3 kJ/m²
Charpy Notch Impact -30℃ 1eA ISO 179 3 kJ/m²
Charpy Un-notch Impact 23℃ ISO 179 100 kJ/m²
Charpy Un-notch Impact -30℃ ISO 179 70 kJ/m²
Flammability Standard Value Unit
Flame Rating 0.400mm UL94 V-0
Flame Rating 0.750mm UL94 V-0
Flame Rating 1.50mm UL94 V-0
Flame Rating 3.00mm UL94 V-0
Limiting Oxygen Index ISO 4589 31 %
Injection molding   Value Unit
Dry Temperature   75~85
Dry Time   4 hr
Water Content Control   ≤0.2 %
Zonel Temperature   260~270
Zone2 Temperature   265~280
Zone3 Temperature   270~280
Melt Temperature   265~280
Mould Temperature   60~90



Application





AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 1 AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 2



AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 3

Optical lighting



It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 4Electronic appliances



It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 5Mechanical equipment



It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields



Physical Property Parameter​

AFR200Y PA66 Material Home Appliance Parts Polyamide 66 Resin Environmental Friendly 6
