Product Details:

Place of Origin: Taiwan, China
Brand Name: Jinlun
Certification: MSDS
Model Number: PA66 A0050FN

Payment & Shipping Terms:

Minimum Order Quantity: 25KG
Price: USD3.8-4.8KG
Packaging Details: PE plastic/paper bag
Delivery Time: 7-15days
Payment Terms: T/T
Supply Ability: 500TONS
Get Best Price Contact Now

Detail Information

Material: PA66 A0050FN Color: Natural Color
Material Shape: Pellets Grade: Injection Molding Grade
Packing: 25 Kg/pack Delivery Time: 7-15days
Port: ShenZhen/GuangZhou,China Ingredient: 100% Virgin Material
Highlight:

Abrasion Resistance Pa66 Plastic Material

,

Low Viscosity Pa66 Plastic Material

,

Abrasion Resistance Pa66 Raw Material

Product Description



Products Description















Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 0















PA66 Jinlun A0050FN enhanced grade flame retardant low viscosity high fluidity thin-walled products



PA66A0050FN because of its flame retardant, easy processing, both flexibility and rigidity, high rigidity and excellent chemical and heat resistance, these characteristics make it in electrical/electronics, automotive manufacturing, mechanical equipment and other fields have a wide range of application prospects.

product feature

PA66
A0050FN
Product information

Part Marking Code >PA66-FR(30)<
Material Shape Pellets
Process Injection molding
FR V-0
Material Attribute Non Halogen
specification ·RoHS ·UL
Additives Flame Retardant Agent
UL File NO. E154352
Certificate W
Physical property Standard Value Unit
Density ASTM D792 1.16 g/cm³
Water Absorption 23℃24hr ASTM D570 0.3 %
Hardness Standard Value Unit
Rockwell Hardness R(Scale) ASTM D785 115
Mechanical behavior Standard Value Unit
Tensile Strength Yield ASTM D638 76 MPa
Elongation Break ASTM D638 8.5 %
Flexural Strength ASTM D790 124 MPa
Flexural Modulus ASTM D790 3308 MPa
Izod Notch Impact 23℃ ASTM D256 43 J/m
Thermal Standard Value Unit
HDT 1.8MPa ASTM D648 110
Melting Temperature ASTM D789 260
CLE ASTM D696 7E-5 cm/cm/℃
Flammability Standard Value Unit
Flame Rating All Color 0.25mm UL94 V-0
Flame Rating AllColor 0.38mm UL94 V-0
Flame Rating All Color 0.8mm UL94 V-0
Flame Rating All Color 3.0mm UL94 V-0
UL Standard Value Unit
UL FlameRating ALL 0.25mm UL94 V-0
UL FlameRating ALL0.38mm UL94 V-0
UL FlameRating ALL 0.8mm UL94 V-0
UL FlameRating ALL 3.0mm UL94 V-0
HWI ALL0.25mm UL 746A 0 PLC
HWI ALL 0.38mm UL746A 0 PLC
HWI ALL 0.8mm UL 746A 0 PLC
HWI ALL 3.0mm UL746A 0 PLC
HAI ALL0.25mm UL746A 0 PLC
HAI ALL0.38mm UL746A 0 PLC
HAI ALL0.8mm UL746A 0 PLC
HAI ALL3.0mm UL746A 0 PLC
RTI Elec ALL 0.25mm UL 746B 65
RTI Elec ALL0.38mm UL 746B 120
RTI Elec ALL 0.8mm UL746B 120
RTI Elec ALL 3.0mm UL 746B 120
RTI Imp ALL0.25mm UL746B 65
RTI Imp ALL 0.38mm UL746B 105
RTI Imp ALL0.8mm UL 746B 105
RTI Imp ALL 3.0mm UL 746B 105
RTI Str ALL0.25mm UL 746B 65



Application





Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 1 Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 2



Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 3

Optical lighting



It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 4Electronic appliances



It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Abrasion Resistance Pa66 Plastic Material Low Viscosity High Fluidity 5Mechanical equipment



It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields



Physical Property Parameter​
